6W 24VDC High CRI LED Module for SEG Fabric Light Box
Solve color inaccuracy in light box graphics with our edge-lit high CRI LED module. Enjoy excellent color reproduction and vibrant graphics across various environments. Advanced optics eliminate lighting inconsistencies. User-friendly installation and adaptable design cater to various applications. Customization available for specific project requirements.
Model ME102RX4
Key Features
- High CRI LEDs
- Elite Optics
- Onboard Constant Current Driver Unit.
- Customization welcomed
Quick Specs
- 6 LEDs
- CRI(Ra) 95
- 24 V DC
- 6 W
- 600 Lumens
- Body Length 290 mm (≈11.5 in.)
Description
Is color inaccuracy holding your light boxes back? Our edge-lit high CRI LED module offers a robust solution. Designed for single and double-sided SEG light boxes, tension fabric light box displays, and sign cabinets, it significantly enhances visual impact while maintaining reliability.
High CRI LEDs deliver excellent color accuracy, bringing your graphics to life with vivid, true-to-life hues. This proves especially valuable for brand consistency and detailed product presentations. The module maintains consistent performance across various environments, from bright retail spaces to dimmer exhibition halls.
We’ve also prioritized practicality. The advanced optics enable taller, slimmer light box designs, and installation is refreshingly straightforward with our plug-and-play approach.
Leveraging our deep industry knowledge, we’re well-equipped to explore customization options that align with your specific requirements and budget. Let’s collaborate to enhance your display solutions and help your visuals make a lasting impression.
Check out other Lumening Edge lit LED module for light boxes
Specifications
All specs open to customization
| Model Number | ME102RX4 |
| Power Consumption | 6 W |
| Power per LED | 1 W |
| Input Voltage | 24 V DC |
| Luminous Flux | 600 lumens ±5% |
| Beam Angle | 9°×54° |
| Optic Material | PMMA |
| CCT Correlated Color Temperature | 6500 K 2500–7000 K Available for your selection |
| Light Color | Pure White |
| CRI (Ra) Color Rendering Index | 95 |
| LED QTY. | 6 LEDs |
| LED Source | EPISTAR, SANAN |
| Chip Size | 30303.0×3.0 mm |
| PCB Type | Aluminum Backed |
| Cuttable | No |
| Dimmable | No We’ve designed this LED module with dimming capabilities which is NOT activated by default. If you want it dimmable, let us know before production. |
| Body Dimensions | 290L×23W×15H mm mm (≈11.5L×1W×0.5H in.) |
| Length incl. Connectors | ≈455 mm (≈18 in.) |
| LED Spacing | 50 mm (≈2 in.) |
| IP Rating Ingress Protection Rating | IP20 |
| Waterproof | No |
| Lifespan | >50000 hours |
| Operating Temperature | -30–60 °C (-22–140 °F ) |
| Place of Origin | GuangDong, China |
Features
High CRI LEDs:
This module uses CRI(Ra) 95 LEDs as the light source, elevating light box displays with exceptional color reproduction, enhancing visual appeal and brand consistency, ensuring vibrant, lifelike graphics; improving legibility, and professional appearance across various environments. Experience true-to-life colors that captivate viewers’ attention.
Elite Optics
The advanced high-transmittance 9°×54° optics ensure bright and even illumination for 6.5-20 cm deep single-sided and 13-35 cm deep double-sided light boxes.
Onboard Constant Current Driver
The onboard constant current driver unit provides stable power to the LEDs for optimal performance, preventing flickering and extending their lifespan.
Easy Installation
Mount this LED module easily on light box aluminum extrusion with thumb screws or thermally conductive adhesive tapes. No professional skill is needed.
Foolproof Connections
Plug-and-play connections from module to module or driver. The Reverse-Polarity Protection design ensures it’s safe and operational even if connections are reversed. Enjoy a worry-free setup.
Efficient Heat Dissipation
The aluminum PCB rapidly transfers heat away from the LEDs, guaranteeing peak functioning and longevity.
5-year Warranty
We back this product with a 5-year warranty. Should it fail due to manufacturing defects, we will repair or replace it at no charge.
Applications
- Single-sided light boxes, Depth: 6.5–20 cm (≈2.5–7.5 in.)
- Double-sided light boxes, Depth: 13–35 cm (≈5–13.5 in.)
- LED light box displays and LED backlit graphic signs
- Frameless SEG light box and LED canvas light boxes
- Tension graphics and bespoke light boxes
- Standing and wall-mounted light boxes and sign boxes
- Sign boxes and sign cabinets
- Stretch ceilings
- Wall washers
