Dimmable 3w edge lit single LED module with high power CREE LED for light box

24V 3W Edge-lit Single LED Module with CREE High Power LED

Say goodbye to uneven lighting with this 3w edge-lit single LED module. This small module fills short empty frame sections in light boxes, ensuring consistent illumination. Featuring a CREE LED, advanced optics for thin displays, and compact-size WAGO connectors for confined spaces, it’s designed to take your lighting projects to the next level.

Key Features
  • CREE High-power LED
  • WAGO Connectors
  • Elite Optic
  • PWM Dimmable
  • Onboard Constant Current Driver Unit.
  • Customization welcomed
  • 5-year warranty
Quick Specs
  • 1 LED
  • 24 V DC
  • 3 W
  • 200 Lumens
  • Body Length 115 mm (≈4.5 in.)
Category: Tags: , , , ,

Description

Dealing with inconsistent lighting in your light boxes? This 3w edge-lit single LED module might be just what you need. Its small size allows it to fit in limited empty sections on light box frames where many LED modules are too long to mount on, eliminating darker areas on displayed graphics caused by inefficient illumination.

We’ve equipped it with a high-quality CREE LED and premium optics, enabling taller and thinner light boxes. It’s also dimmable, offering you precise control over your lighting.

For hassle-free installation, we use reliable WAGO SMD connectors. These reliable, compact sized connectors ensure secure, long-lasting connections in confined spaces.

With our decade of LED lighting expertise, we’re committed to supporting your lighting needs. We offer customization options to perfectly match your project requirements. Let’s collaborate to enhance your displays.

Specifications

    All specs open to customization
Power Consumption3 W
Power per LED3 W
Input Voltage24 V DC
Luminous Flux200 lumens ±5%
Beam Angle9°×54°
Optic MaterialPMMA
CCT Correlated Color Temperature6500 K 2500–7000 K Available for your selection
Light ColorPure White
CRI (Ra) Color Rendering Index 75-85
LED QTY.1 LED
LED Model CREE XT-E
Chip Size3535 3.5×3.5 mm
PCB TypeAluminum Backed
CuttableNo
DimmableYes
Dimming Protocol5v PWM
Body Dimensions115L×23W×14H mm (≈4.5L×1W×0.5H in.)
IP Rating Ingress Protection RatingIP20
WaterproofNo
Lifespan>50000 hours
Operating Temperature-30–60 °C (-22–140 °F )
Place of OriginGuangDong, China



Features

  • Compact Design:

The Module’s Compact design allows it to fit into short sections of light box frames where longer modules can not, seamlessly integrating with longer modules to eliminate dark areas and ensure even illumination.

  • CREE High-power LEDs

This module uses CREE XLamp XT-E, XP-G, and XP-E High-power LED as the light source for high efficacy and exceptional performance. Prefer other LEDs? We can use different high-quality options to fit your needs.

  • Elite Optic

The advanced high-transmittance 9°×54° optic ensures bright and even illumination for 6.5-20 cm deep single-sided and 13-35 cm deep double-sided light boxes.

  • WAGO Connectors

WAGO connectors’ compact size enables high wiring density in confined spaces while offering quick, tool-free connections and secure, maintenance-free reliability. The Reverse-Polarity Protection design ensures it’s safe and operational even if connections are reversed. Enjoy a worry-free setup.

  • Dimmable

5V PWM dimming enables seamless light output adjustment via dedicated dimming channel, offering flexible light output and energy optimization.

  • Onboard Constant Current Driver

The onboard constant current driver unit provides stable power to the LED for optimal performance, preventing flickering and extending their lifespan.

  • Easy Installation

Mount this LED module easily on light box aluminum extrusion with thumb screws or thermally conductive adhesive tapes. No professional skill is needed.

  • Efficient Heat Dissipation

The aluminum PCB rapidly transfers heat away from the LEDs, guaranteeing peak functioning and longevity.

  • 5-year Warranty

We back this product with a 5-year warranty. Should it fail due to manufacturing defects, we will repair or replace it at no charge.

Applications

  • Single-sided light boxes, Depth: 80–150 mm (≈3–6 in.)
  • Double-sided light boxes, Depth: 160–300 mm (≈6–12 in.)
  • LED light box displays and LED backlit graphic signs
  • Frameless SEG light box and LED canvas light boxes
  • Tension graphics and bespoke light boxes
  • Standing and wall-mounted light boxes and sign boxes
  • Sign boxes and sign cabinets
  • Stretch ceilings
  • Wall washers
